PRODUCT SPECIFICATIONS
Ubiquiti USW-PRO-8-POE
An 8-port, Layer 3 switch with PoE+ and PoE++ output.
Key Features:
- 1.3' touchscreen with AR switch management
- (6) GbE, PoE+ RJ45 ports
- Reset button
- 120W total PoE suplly
- (2) 10G SFP ports
- Wall-mountable (kit included)
- Power input
- Safety latch
Technical Specification:
- Overview:
- Dimensions: 200 x 248 x 44 mm (7.9 x 9.8 x 1.7')
- Port Layout:
- 1 GbE RJ45: 8 (6 PoE+; 2 PoE++)
- 10G SFP+: 2
- Max. PoE Output: Up to PoE++
- Total PoE Availability: 120W
- Layer 3
- Form Factor: Compact desktop, wall
- Performance:
- Switching Capacity: 56 Gbps
- Total Non-Blocking Throughput: 28 Gbps
- Forwarding Rate: 42 Mpps
- Supported VLANs: 1,000
- MAC Address Table Size: 16,000
- L3 Table Size
- ARP Entries: 6,000
- IPv4 Routes: 512
- Packet Buffer Size: 1.5 MB
- Layer 3 Features:
- DHCP Server (Local Networks)
- DHCP Relay
- Inter-VLAN Routing (Local Networks)
- Static Routing (Local Networks)
- Layer 2 Features:
- LACP Port Aggregation
- STP & RSTP
- Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
- IGMP Snooping
- 802.1X Control
- MAC-Based ACLs & Device Isolation
- DHCP Snooping & Guarding
- Egress Rate Limit
- Flow Control
- Storm Control
- Multicast & Broadcast Rate Limiting
- MAC Address Blocking
- IP-Based ACLs & Network Isolation
- MAC-Based Port Restriction
- Port Isolation
- Port Mirroring
- Jumbo Frames
- LLDP-MED
- Voice VLAN
- Loop Protection
- Hardware:
- PoE Ports:
- PoE+: 6
- PoE++: 2
- Max. PoE Wattage per Port by PSE:
- PoE: 15.4W
- PoE+: 32W
- PoE++: 64W
- Max. Power Consumption:
- 30W (Excluding PoE Output)
- 150W (Including PoE Output)
- Power Method: Universal input, 100—240V AC, 50/60 Hz
- Power Input Method: AC input
- Power Supply: AC/DC, internal, 150W
- Supported Voltage Range: 100—240V AC
- Management:
- Ethernet
- AR
- Heat Dissipation (Excluding PoE Output): 102.36 BTU/hr
- Weight: 2.1 kg (4.6 lb)
- Enclosure Material: Polycarbonate, metal
- Mount Material: Polycarbonate
- LCM Display: 1.3' touchscreen
- Ambient Operating Temperature: -5 to 45° C (23 to 113° F)
- Ambient Operating Humidity: 10 to 90% noncondensing
- Certifications: CE, FCC, IC
- PoE Ports:
More Information
MFRPartNum:
USW-Pro-8-PoE
