PRODUCT SPECIFICATIONS
USW-Pro-Max-16-PoE: 16-Port Layer 3 Managed Switch with 4x 2.5GbE PoE++, 12x 1GbE PoE+, and 2x SFP+ Ports (180W PoE Power)
The USW-Pro-Max-16-PoE is a versatile 16-port Layer 3 Etherlighting™ switch designed with 2.5 GbE, PoE++ output, and advanced networking features. This switch is ideal for enterprise environments requiring high-speed data transfer and PoE capabilities, with a total PoE availability of 180W. It offers multiple mounting options, including desktop, wall, and rack mounts, and features a silent, fanless cooling system for reliable operation in various settings.
Highlights
- Etherlighting™ Ports: Ports illuminate to indicate port location, speed/link status, and native VLAN/network.
- Silent Operation: Equipped with a fanless cooling system, ensuring quiet performance.
- Versatile Mounting: Can be mounted on a desktop, wall, or rack (requires add-on rack mount accessory).
- Touchscreen LCM Display: 1.3' touchscreen for easy monitoring and configuration.
- Networking Interfaces:
- 12 x GbE RJ45 PoE+ ports
- 4 x 2.5 GbE RJ45 PoE++ ports
- 2 x 10G SFP+ ports
- PoE Capabilities:
- PoE: 15.4W per port
- PoE+: 30W per port
- PoE++: 60W per port
- Total PoE availability: 180W
Technical Description
- Mechanical:
- Dimensions: 325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7')
- Weight: 2.1 kg (4.6 lb)
- Enclosure Material: SGCC steel
- Hardware:
- Management Interface: Ethernet In-Band
- Power Supply: 54V, 210W DC adapter
- Max. Power Consumption: 30W (excluding PoE output)
- Networking Interface:
- (12) GbE RJ45 ports
- (4) 1/2.5 GbE RJ45 ports
- (2) 10G SFP+ ports
- Switching Features:
- Total non-blocking throughput: 42 Gbps
- Switching capacity: 84 Gbps
- Forwarding rate: 62.496 Mpps
- Layer 2 Features: IGMP snooping, STP/RSTP, port isolation, storm control, voice VLAN, port mirroring, LACP port aggregation, and more.
- Layer 3 Features: DHCP for locally-managed networks, DHCP relay, inter-VLAN routing, static routing, and network isolation with ACLs.
- Ambient Operating Conditions:
- Temperature: -5 to 40° C (23 to 104° F)
- Humidity: 10 to 90% noncondensing
- Certifications: CE, FCC, IC
- This switch is fully integrated with the UniFi Network platform, offering seamless management and monitoring capabilities through the UniFi controller, ensuring efficient network operation.
- Application Requirements:
- Requires UniFi Network Version 8.1.127 and later for full functionality.
More Information
MFRPartNum:
USW-PRO-MAX-16-POE
Datasheet:
