PRODUCT SPECIFICATIONS
Wave Pico - Ubiquiti Lightweight, compact 60 GHz PtMP station
The Wave Pico is a lightweight and compact 60 GHz Point-to-Multipoint (PtMP) station designed for high-speed and low-latency wireless connectivity. This device, powered by Wave Technology, is ideal for outdoor deployment, providing robust performance in various environments.
Features:
- Compact Design: The small and lightweight design makes it easy to install and manage.
- High Performance: Capable of delivering up to 2 Gbps total throughput with a maximum range of up to 1.3 km when connected to a Wave AP.
- Weatherproof: Built with a weatherproof IPX6 enclosure for reliable outdoor use.
- Flexible Power Options: Can be powered via Passive PoE or using a UISP Router or UISP Switch.
- Easy Management: Managed through the UISP web application or mobile app, offering tools like antenna alignment, speed tests, and site surveys.
Applications:
- Outdoor Wireless Networks
- Long-Range Point-to-Multipoint Connections
- High-Speed Data Links for Urban and Rural Areas
Compatibilities
- US version
Technical Description
- Mechanical
- Dimensions: Ø152.1 x 55.8 mm (Ø6 x 2.2')
- Weight: 347 g (12.2 oz) without mount; 409 g (14.4 oz) with mount
- Enclosure Material: UV stabilized polycarbonate
- Mount Material: UV stabilized polycarbonate
- Pole Mount Diameter: 20 to 53.1 mm (0.8 to 2.1')
- Wind Loading: 31.3 N at 200 km/h (7 lbf at 125 mph)
- Weatherproofing: IPX6
- Hardware
- Processor: Dual-core ARM® Cortex®-A53 at 1 GHz
- Memory: DDR3L 512 MB
- Networking Interface: (1) GbE RJ45 port
- Max. Power Consumption: 10W
- Power Method: Passive PoE 4-pairs or 2-pairs
- Power Supply: 48V DC, 0.5A gigabit PoE adapter included
- Supported Voltage Range: 44–54V DC; 22–27V DC
- Operating Temperature: -40 to 60° C (-40 to 140° F)
- Operating Humidity: 5 to 95% noncondensing
- Certifications: FCC, IC, CE
- Software
- Operating Mode: PtMP station, PtP
- Ubiquiti Specific Features: Wave AI, discovery protocol
- Management Services: UISP, ping watchdog, NTP client, SNMP
- Tools: Antenna alignment, discovery utility, speed test, site survey
- System
- Total Throughput: 2 Gbps (1 Gbps duplex)
- Max. Range: Up to 1.3 km (Wave AP); up to 0.9 km (Wave AP Micro)
- Encryption: WPA2-PSK (AES)
- RF
- Operating Frequency: 57–71 GHz (Depends on regulatory region)
- Channel Bandwidth: 2160, 1080, 540 MHz
- Modulation: 16QAM, QPSK
- Antenna Gain: 27.7 dBi
- Polarization: Vertically linear
- Beamwidth: Azimuth: 3 dB 6°; Elevation: 3 dB 6°
- Back-Up RF
- WiFi Standard: 802.11ax (WiFi 6)
- Operating Frequency: 5150 - 5850 MHz (Depends on regulatory region)
- Channel Bandwidth: 20, 40, 80 MHz
- Antenna Gain: 9 dBi
More Information
MFRPartNum:
WAVE-PICO
