PRODUCT SPECIFICATIONS
V-SOL V2802DAC XPON ONT with AC1200 Wi-Fi 5
The V-SOL V2802DAC combines GPON/EPON fiber access, dual-band Wi-Fi 5 and two Gigabit Ethernet ports in a subscriber gateway for fiber-to-the-home networks.
Designed for operator-provisioned broadband, it supports wired computers and network devices alongside wireless clients. Bridge, router and mixed operation modes provide deployment flexibility for residential and small-office networks.
Key Features
- One XPON port with automatic GPON/EPON mode detection.
- AC1200-class Wi-Fi on 2.4 GHz and 5 GHz bands.
- Two RJ45 Gigabit Ethernet ports.
- EasyMesh support and multiple SSIDs.
- IPv4/IPv6 dual stack.
- Single-mode SC/UPC optical connection.
Wireless Performance
Each wireless band supports 2×2 MIMO. The published combined PHY rate is up to 1167 Mbps, marketed as AC1200. Actual throughput depends on clients, channel conditions, interference and the broadband service.
Fiber and Ethernet Connectivity
The XPON interface supports GPON Class B+ and EPON PX20+. The Ethernet ports provide Gigabit connectivity for wired equipment. Fiber activation requires compatible OLT provisioning and an optical path within the network's power budget.
Routing and Network Management
OAM/OMCI, TR-069 and web management support operator administration. VLAN functions, multicast snooping/proxy and QoS help configure subscriber traffic and IPTV services where provided by the operator.
Power
The documented external adapter is rated at 12V DC, 1A, with device consumption up to 12W. PoE powering is not documented.
Ideal Applications
- Operator-managed residential FTTH broadband.
- Small-office fiber access with wired and wireless clients.
- Provisioned Internet and IP multicast/IPTV services.
Compatible Products
Use a compatible, provisioned GPON or EPON OLT and single-mode fiber infrastructure. Confirm ONU authentication, firmware, OMCI/OAM service profiles and the optical budget before deployment.
- Ubiquiti UACC-OFC-SM-PATCH-UPC-APC Single-Mode Fiber Patch Cord, 1.5 m – suitable for connecting the documented SC/UPC ONT port to an SC/APC distribution outlet. Connect the blue SC/UPC end to the ONT and the green SC/APC end to the outlet; include insertion loss in the optical budget.
Important: Do not insert an SC/APC plug directly into an SC/UPC port. This cable recommendation covers the passive fiber connection, not ISP activation or OLT interoperability. Regional V2802DAC units may have a different optical connector; verify the actual unit before choosing a patch cord.
EasyMesh support does not establish a verified pairing with every mesh device. No specific OLT, mesh partner or replacement power adapter is represented here as an approved combination for Flytec's unspecified hardware and firmware revision.
Technical Specifications
General
- Manufacturer: V-SOL.
- Model / SKU / listed MPN: V2802DAC.
- Product type: XPON fiber ONU/ONT gateway.
Fiber and Optical Interfaces
- PON interface: 1 × XPON.
- PON modes: GPON Class B+ and EPON PX20+.
- Connector: SC/UPC, single-mode, as documented for the Flytec listing.
- Wavelengths: 1310 nm transmit; 1490 nm receive.
- Transmit optical power: 0 to +4 dBm.
- Receive sensitivity: -27 dBm.
- Receive overload: -3 dBm EPON; -8 dBm GPON.
- Published reach: Up to 20 km, subject to optical budget and network design.
Ethernet
- Ports: 2 × RJ45 Gigabit Ethernet.
- Maximum port link rate: 1000 Mbps per port.
- Functions: Auto-negotiation and Auto-MDI/MDIX.
- LAN1 Ethernet WAN mode: Listed in current manufacturer documentation; confirm availability on the supplied revision.
Wireless
- Standards: IEEE 802.11b/g/n/ac.
- Bands: 2.4 GHz and 5 GHz.
- MIMO: 2×2 per band.
- Wireless class: AC1200; combined PHY rate up to 1167 Mbps.
- Functions: EasyMesh and multiple SSIDs.
- Antenna gain: 5 dBi in Flytec's listing and matching legacy datasheet.
Routing, Switching and Management
- Modes: Bridge, router and mixed bridge/router.
- IP: IPv4/IPv6 dual stack.
- Routing: Static routes, DHCP server, PPPoE, NAT, DMZ and DDNS.
- VLAN: Tagging, untagging, transparent, trunk and translation modes.
- Multicast: IGMP v1/v2/v3 and MLD v1/v2 snooping/proxy.
- QoS: Four queues; SP, WRR, 802.1p and DSCP.
- Management: OAM/OMCI, web, Telnet and TR-069.
- Security functions: Firewall, ACL and MAC/URL filtering.
Power
- External adapter: 12V DC, 1A.
- Device consumption: ≤12W.
- PoE: Not documented; use the specified DC supply.
- DC plug size, polarity and regional AC input: Not reliably confirmed for Flytec's exact bundle.
Physical and Environmental
- Dimensions: 178 × 120 × 30 mm (L × W × H).
- Net weight: 0.31 kg.
- Operating temperature: 0 to +55°C in Flytec's listing and matching legacy datasheet.
- Operating humidity: 10–90%, non-condensing, in the matching legacy datasheet.
- Storage temperature: -30 to +60°C in the matching legacy datasheet.
- Storage humidity: 10–90%, non-condensing, in the matching legacy datasheet.
Included Parts
The manufacturer lists a 12V DC, 1A AC-DC adapter as an accessory. Exact Flytec bundle contents and regional plug type are not independently confirmed.
