V-Sol V8816W-16P 16-Port 1550nm High Power PON EYDF 40dBm Output CWDM CATV PON Compatibility

V-Sol V8816W-16P 16 Ports 1550nm High Power PON EYDF

The V8816W-16P Series 1550nm fiber amplifier combines low-noise EDFA and high-power EYDFA.The total output optical power can reach 40dBm, Optical power of 1550nm per output port not less than 19 dBm/22dBm (optical power level selectable),replacing multiple EDFA units. Each output port is built in with CWDM to multiplex CATV signal and OLT PONDataflow,IdealforFTTH applications.This product offers excellent performance and reliability and supports network management and power redundancy.

Key Features

• It adopts the top brand pump laser and double cladding active fiber.
• Each output port is built in with CWDM.
• Compatible with any FTTx PON：EPON、GPON、10GPON.
• Perfect APC, ACC and ATC optical circuit design ensures low noise, high output and highreliabilityofthe device in the whole operating band (1545 ~ 1565nm).
• It has the function of automatic protection of low input or no input. When the input optical powerislower than the set value, the laser will automatically shut down to protect the operating safetyof thedevice.
• Output adjustable, adjustment range : 0~-4dBm.
• CATV/PON dual fiber inputs
• The switching time of optical switch is short and the loss is small. It has the functions of automaticswitching and forced manual switching.
• Built- in dual power supply, automatically switched and hot plug supported.
• The operating parameters of the whole machine are controlled by microprocessor, and theLCDstatus display on the front panel has many functions such as laser status monitoring, parameter display, fault alarm, network management, etc.; once the operating parameters of the laser deviatefrom the allowed range set by the software, the system will alarm promptly.
• Standard RJ45 interface is provided, supporting SNMP and WEB remote network management.
