PRODUCT SPECIFICATIONS
AirLive SmartCube 300W 3MP Indoor Wireless IP Camera
The AirLive SmartCube 300W combines indoor video monitoring with PIR detection, two-way audio and environmental sensing. Designed for homes, offices and shops, this cube-style IP camera connects through WiFi or a wired Ethernet network.
The camera supports 2048 x 1536 video at up to 20 fps and Full HD 1080p at up to 30 fps. Its built-in microphone and speaker support voice communication, while infrared illumination and a mechanical IR-cut filter provide day/night operation.
Key Features
- 3MP video capture with selectable lower-resolution streams.
- 802.11n WiFi and a 10/100 Mbps Ethernet connection.
- PIR detection for event-based monitoring.
- Built-in microphone and speaker for two-way audio.
- Temperature and humidity sensors with configurable alerts.
- Infrared night vision and mechanical IR-cut filter.
- MicroSDXC card slot for local recording.
- Documented ONVIF Profile S and RTSP support.
Video and Night Vision
A fixed 3.6 mm lens provides coverage for indoor monitoring. Ten infrared LEDs provide a manufacturer-listed illumination distance of up to 15 m. Actual night-image detail depends on the scene, subject distance and reflective surfaces.
Detection and Application Modes
Documented functions include PIR detection, video motion detection and configurable video analytics. DoorCAM and Store Entrance scenarios provide application-specific settings for entrance monitoring and counting. Analytics require suitable positioning and configuration.
Temperature and Humidity Monitoring
The camera can display environmental readings and generate events when configured thresholds are crossed. These sensors provide general monitoring information and should not be treated as precision measurement instruments.
Connectivity and Recording
Choose a wireless network connection or connect the RJ45 port to a compatible Ethernet switch. Local recording uses the microSDXC slot; recording settings and storage media must be configured separately.
Power and Indoor Installation
The SmartCube 300W requires 5 V DC power from its external adapter. Wireless connectivity does not eliminate the power connection. Install indoors in a location protected from rain and moisture.
Ideal Applications
- Indoor home and office monitoring.
- Shop entrance observation and configured counting applications.
- Two-way communication at indoor entrances.
- General temperature and humidity awareness alongside video.
Compatible Products
The camera supports wired Ethernet networking, documented ONVIF Profile S integration and an AirLive smart-home integration described by the manufacturer. Each connection has different requirements.
- Manhattan 560689 8-Port Fast Ethernet Switch – provides a compatible 10/100 Mbps Ethernet data connection. The camera still requires its separate 5 V DC power adapter.
Important: ONVIF Profile S support does not guarantee that every NVR will support every camera feature. Confirm video-stream, codec, audio and recording compatibility with the exact recorder and firmware. Do not assume that the Ethernet port accepts PoE. Replacement power adapters require verification of voltage, current, connector dimensions and polarity.
Technical Specifications
General
- Brand: AirLive
- Model / Flytec SKU: SmartCube 300W
- Manufacturer Designation: SC-300W
- Product Type: Indoor wireless cube IP camera
Processor and Memory
- Processor: TI DMVA2
- Flash Memory: 128 MB NAND
- RAM: 128 MB DDR SDRAM
Imaging and Lens
- Image Sensor: 1/3-inch CMOS
- Maximum Resolution: 2048 x 1536, 3MP
- Lens: Fixed 3.6 mm, F2.0
- Viewing Angles: 80° diagonal, 72° horizontal, 47° vertical
- Digital Zoom: 10x
Video
- Maximum 3MP Frame Rate: 20 fps at 2048 x 1536
- Full HD Frame Rate: 30 fps at 1920 x 1080
- 720p Frame Rate: 30 fps at 1280 x 720
- Compression: H.264, MPEG-4 and MJPEG
- Image Functions: WDR, 3D noise reduction, backlight compensation, privacy masking and mirror/flip
Night Vision and Detection
- IR LEDs: 10
- Listed Maximum IR Distance: 15 m
- IR-Cut Filter: Mechanical ICR
- PIR Sensor: Built in
Audio and Environmental Sensors
- Audio: Built-in microphone and speaker; two-way communication
- Audio Codec: G.711
- Temperature Sensor Range: 0 to 55°C
- Listed Temperature Accuracy: Within approximately 5°C
- Humidity Sensor Range: 0 to 90%
- Listed Humidity Accuracy: Within approximately 10%
Network and Storage
- Ethernet: 1 x RJ45, 10/100 Mbps
- Wireless: 2.4 GHz, IEEE 802.11n
- Integration: Manufacturer-documented ONVIF Profile S and RTSP
- Local Storage: MicroSDXC card slot
Power
- Power Supply: 5 V DC, 1 A
- Power Connection: DC power jack
- Maximum Listed Consumption: 4 W
Physical and Environmental
- Dimensions: 94 x 64 x 40 mm (H x W x D)
- Installation: Indoor
- Operating Temperature: -5 to +55°C
- Operating Humidity: 20 to 85%, noncondensing
- Storage Temperature: -15 to +60°C
Original Manufacturer Package Contents
- SmartCube 300W camera
- Stand
- Power adapter
- Mounting accessories
- Quick Setup Guide
Download AirLive SmartCube 300W SC-300W IP Camera Datasheet (PDF)
