Tycon Wireless EZGO-0214+ 2.4GHz AP/Client with 14dBi MIMO Antenna and 24V PoE Power Inserter



The EZ-Go is a high power 25dBm (316mW) outdoor wireless access point or client device operating in the 2.4GHz or 5GHz unlicensed frequency spectrum providing real world throughput up to 100 Mb/sec. It complies with the 802.11g/n or 802.11a/n standards to insure interoperability.

It supports VOIP, VPN, multiple MAC addresses and DHCP.

With its password verification, MAC address authentication, SSID suppression and advanced WPA encryption, the system provides the best available wireless data security. If changes to the pre-configured settings are desired, they can be easily done thru the built-in web interface. There are no drivers or software that needs to be loaded to the computer.

The EZ-Go comes complete with a powerful 14dBi 802.11g/n or 16dBi 802.11a/n MIMO antennas with built-in high power electronics, Bracket Kits which accommodate pole or wall mounting and Cat5e rated PoE (Power over Ethernet) power inserters with 24VDC auto-ranging power supplies. Customer needs to supply CAT5 cabling between the power inserter and the antenna and between the power inserter and his computer, router or switch.
With its advanced software, the EZ-Go supports multiple operating modes, including; Access Point, Access Point (WDS), Client, Client (WDS), WAN Gateway, WLAN Gateway


  • High Power 250mW Electronics and powerful 14dBi antenna. EIRP = 6.3W
  • Advanced EZOS Software
  • 64 and 128bit WEP, WPA and WPA2 Encryption
  • Seamless Roaming
  • DHCP Client or Server
  • MAC Address filtering
  • VOIP Friendly QOS
  • SNMP
  • Power over Ethernet (PoE)
  • EZ-Bridge® Network Expansion


  • Operation at long distances and up to 100 Mb/sec
  • No driver needed. Easy configuration thru web interface and remotely. Multiple Operating Modes. Plug and Play installation. Antenna alignment utility. Bandwidth management. Data Logging and statistics graphing.
  • Most powerful data security available
  • Allows users to roam between access points without loss of connection
  • Simplifies network administration
  • Ensures secure network connection in all operating modes
  • Quality Of Service mechanism to ensure good Voice Over IP performance
  • Compatible with your favorite network management software
  • Antennas can be mounted up to 100meter (300’) from the power source
  • EZ-Go® are compatible with the EZ-Bridge® wireless bridge systems and can be used to expand the network to multiple buildings

Complete System Weight

  • 1.4 kg (3 lbs )

Technical Description

  • Data Rates: 2.4Ghz 802.11n: up to 300Mbps 2.4 GHz 802.11g: up to 54Mbps
  • Standards: IEEE802.11g/n, 802.11a/n, 802.3, 802.3u
  • Power Requirements: Power Supply: 100-240VAC 50/60Hz / EZ-Bridge®: 12VDC to 24VDC Passive PoE / Average Power Consumption: 4W
  • Regulatory Certifications: FCC Part 15 / UL
  • RF Frequency Band: 2400 ~ 2497 MHz
  • Modulation Technology: 802.11n: TDMA / 802.11g: OFDM / 802.11a: OFDM
  • Receive Sensitivity (Typical): 802.11n: -90 dBm / 802.11g: -75 dBm / 802.11a: -75 dBm
  • Transmit Power: 25dBm  316mW
  • DC Connector Power Out Input Voltage: @ Max 10W
  • Antenna: 2.4GHz 14dBi MIMO Panel Antenna, 35deg Beamwidth, >20dB front to back
  • Operation Mode – Bridge or Router: Access Point, Access Point WDS, Client, Client WDS, WAN Gateway, WLAN Gateway
  • Interface: 10/100Mbps RJ-45 LAN Port x 2
  • IP Configuration: Static or Auto configuration using DHCP Client
  • Security MAC Address: Filtering, WEP/WPA encryption, Hide SSID in beacons, Layer 2 isolation
  • Management Configuration: Web-based configuration (HTTP) / Console configuration (SSH) / SNMP Protocol
  • Firmware Upgrade: Upgrade firmware via web browser
  • Antenna Physical Dimensions (L x W x D): 314mm x 187mm x 65mm (12.4” x 7.3” x 2.5”)
  • Operating Temperature: -30°C to +70°C (-22°F to 158°F)
