PRODUCT SPECIFICATIONS
Ubiquiti UACC-Rack-12U-Wall-450-P 12U Rack Cabinet
The Ubiquiti UACC-Rack-12U-Wall-450-P is a 12U wall-mount rack cabinet with a perforated front door, built-in fan module, and removable lockable side panels. It ships fully assembled and is designed for easier equipment access in space-efficient small-scale deployments.
The cabinet uses a 4-post enclosed design with square mounting holes, adjustable mounting depth from 283 mm to 305 mm, and support for up to 50 kg. Its reversible front door and rear, top, and bottom cable entry openings help support cleaner rack installation in tight spaces.
Deployment Notes
The unit is compatible with Ubiquiti rack-mount devices up to 325 mm in depth. When the mounting depth is set to 305 mm, 325 mm devices can be installed, but DC power backup is not supported because rear-side clearance is limited.
Key Features
- 12U wall-mount rack cabinet
- Perforated front door with default left-hand outswing and reversible design
- Ships fully assembled
- Built-in fan module
- (2) solid, removable, lockable side panels
- Adjustable mounting depth from 283 mm to 305 mm
- Supports up to 50 kg
- Rear, top, and bottom cable entry openings
Applications
- Space-efficient small-scale network deployments
- Wall-mounted rack installations that need easier front and side equipment access
- Equipment cabinets that benefit from built-in fan ventilation and removable panels
Technical Specifications
- Capacity
- U Height: 12U
- Max. Weight Capacity: 50 kg (110 lb)
- Hardware
- Rack Type: 4 post, enclosed cabinet
- Mounting Hole Type: Square
- Enclosure Material: SPCC steel Door/side panels: 0.8 mm (0.03') Main body: 0.8 mm (0.03') Posts: 2 mm (0.08')
- Color: White
- Treatment: Powder coating
- Front Door: Perforated Default left-hand outswing, reversible
- Side Panels: (2) Solid, removable and lockable
- Fan Module: ✓
- Acoustic Noise: ≤ 50 dB(A) sound pressure level
- Grounding Lugs: ✓
- Supported Devices: Compatible with Ubiquiti rack-mount devices up to 325 mm in depth. Note: 325 mm devices can be installed when the mounting depth is set to 305 mm (max), but DC power backup is not supported due to limited rear-side clearance.
- Security
- Security: (1) Front door lock (4) Side panel locks (2) Keys
- Physical
- Dimensions: Packaging: 580 x 675 x 735 mm (22.8 x 26.6 x 28.9') Rack: 550 x 450 x 635 mm (21.7 x 17.7 x 25')
- Weight: Packaging: 22 kg (48.5 lb) Rack: 17.8 kg (39.2 lb)
- Adjustable Mounting Depth: Default 283 mm (11.1') Max. 305 mm (12') Adjustable pitch 22 mm (0.9')
- Mounting: Wall mount
- Cable Entry Opening: (1) Rear wall: 350 x 100 mm (13.8 x 3.9') (1) Top: 336.5 x 52.5 mm (13.2 x 2.1') (1) Bottom: 336.5 x 52.5 mm (13.2 x 2.1')
- Certifications
- Standard: CE; EIA/ECA-310-E; RoHS
- NDAA Compliant: ✓
