PRODUCT SPECIFICATIONS
Ubiquiti UACC-Rack-42U-800-P 42U Rack Cabinet
The Ubiquiti UACC-Rack-42U-800-P is a fully assembled 42U floor rack cabinet with an 800 mm depth, perforated front and rear doors, built-in fan module, removable panels, and lockable casters. It is designed for organized rack-mounted equipment deployments that need airflow, heavy-duty stability, and easy equipment access.
This 4-post enclosed cabinet supports a static weight capacity of 800 kg (1764 lb) and a rolling weight capacity of 320 kg (705 lb). Ubiquiti notes that delivery may be restricted for certain residential addresses due to the product size and weight, and that delivery is door-to-door only.
Rack Access and Stability
The cabinet includes reversible perforated front and rear doors, four solid removable and lockable side panels, lockable casters, leveling stands, cabinet interconnect support, floor anchor support, grounding lugs, and top and bottom cable entry openings.
Key Features
- Fully assembled 42U floor rack cabinet
- 800 mm rack depth
- 4-post enclosed cabinet design
- Perforated front and rear doors
- Built-in fan module
- Four solid removable and lockable side panels
- Lockable casters and leveling stands
- Static weight capacity of 800 kg (1764 lb)
Applications
- Floor-standing network equipment rack installations
- Organizing UniFi and rack-mounted IT equipment
- Deployments requiring front, rear, and side equipment access
- Rack installations that need built-in airflow support and locking panels
Technical Specifications
- Capacity
- U Height: 42U
- Max. Weight Capacity: Static 800 kg (1764 lb); Rolling 320 kg (705 lb)
- Security
- Security: (1) Front door lock; (1) Rear door lock; (8) Side panel locks; (3) Keys
- Hardware
- Rack Type: 4 post, enclosed cabinet
- Mounting Hole Type: Square
- Enclosure Material: SPCC steel
- Door/Side Panels: 1.2 mm (0.05')
- Main Body: 1 mm (0.04')
- Posts: 2 mm (0.08')
- Color: White
- Treatment: Powder coating
- Front Door: Perforated, default left-hand outswing, reversible
- Rear Door: Perforated, default left-hand outswing, reversible
- Side Panels: (4) Solid, removable and lockable
- Fan Module: Yes
- Grounding Lugs: Yes
- Physical
- Packaging Dimensions: 740 x 965 x 2,223 mm (29.1 x 38 x 87.5')
- Rack with Caster Dimensions: 600 x 800 x 2,050 mm (23.6 x 31.5 x 80.7')
- Rack without Caster Dimensions: 600 x 800 x 1,966 mm (23.6 x 31.5 x 77.4')
- Packaging Weight: 110.4 kg (243.4 lb)
- Rack Weight: 84.6 kg (186.5 lb)
- Adjustable Mounting Depth: Default 607.2 mm (23.9'); Max. 682.2 mm (26.9'); Adjustable pitch 15 mm (0.6')
- Mounting: Floor stand
- Lockable Casters: Yes
- Leveling Stands: Yes
- Cabinet Interconnect: Yes
- Floor Anchor: Yes
- Cable Entry Opening: (2) Top: 335 x 52.5 mm (13.2 x 2.1'); (2) Bottom: 335 x 52.5 mm (13.2 x 2.1')
- Certifications
- Standard: CE; EIA/ECA-310-E; RoHS
- NDAA Compliant: Yes
