PRODUCT SPECIFICATIONS
Ubiquiti UACC-Rack-42U-800-G 42U Rack Cabinet
The Ubiquiti UACC-Rack-42U-800-G is a fully assembled 42U floor rack cabinet with an 800 mm depth, built-in fans, removable panels, and lockable casters. It is designed for organized rack equipment installation with enclosed 4-post construction, tempered glass front access, and heavy-duty static weight capacity.
The rack supports a static weight capacity of 800 kg (1764 lb) and a rolling weight capacity of 320 kg (705 lb). It includes reversible front and rear doors, removable lockable side panels, grounding lugs, cable entry openings at the top and bottom, and support for floor anchoring.
Rack Access and Installation
This cabinet ships fully assembled and is built for floor-standing deployments. The removable lockable side panels, reversible doors, lockable casters, leveling stands, and cable entry openings support easier equipment access, placement, and cable routing in rack installations.
Key Features
- 42U fully assembled floor rack cabinet
- 800 mm rack depth
- 4-post enclosed cabinet with square mounting holes
- Tempered glass front door with reversible left-hand outswing
- Solid rear door with reversible left-hand outswing
- Four solid, removable, and lockable side panels
- Static weight capacity of 800 kg (1764 lb)
- Built-in fan module, grounding lugs, lockable casters, and leveling stands
Applications
- 42U floor-standing rack installations for network and IT equipment
- Enclosed rack deployments requiring removable lockable panels
- Equipment rooms that need front, rear, and side access to installed hardware
- Rack installations requiring top and bottom cable entry openings
Technical Specifications
- Capacity
- U Height: 42U
- Max. Weight Capacity: Static 800 kg (1764 lb); Rolling 320 kg (705 lb)
- Security
- Security: (1) Front door lock; (1) Rear door lock; (8) Side panel locks; (3) Keys
- Hardware
- Rack Type: 4 post, enclosed cabinet
- Mounting Hole Type: Square
- Enclosure Material: SPCC steel; Door/side panels: 1.2 mm (0.05'); Main body: 1 mm (0.04'); Posts: 2 mm (0.08')
- Color: White
- Treatment: Powder coating
- Front Door: Tempered glass; Default left-hand outswing, reversible
- Rear Door: Solid; Default left-hand outswing, reversible
- Side Panels: (4) Solid, removable and lockable
- Lockable Casters: Yes
- Leveling Stands: Yes
- Cabinet Interconnect: Yes
- Floor Anchor: Yes
- Fan Module: Yes
- Grounding Lugs: Yes
- Physical
- Dimensions: Packaging: 740 x 965 x 2,223 mm (29.1 x 38 x 87.5'); Rack with caster: 600 x 800 x 2,050 mm (23.6 x 31.5 x 80.7'); Rack without caster: 600 x 800 x 1,966 mm (23.6 x 31.5 x 77.4')
- Weight: Packaging: 118.6 kg (261.5 lb); Rack: 92.4 kg (203.7 lb)
- Adjustable Mounting Depth: Default 607.2 mm (23.9'); Max. 682.2 mm (26.9'); Adjustable pitch 15 mm (0.6')
- Mounting: Floor stand
- Cable Entry Opening: (2) Top: 335 x 52.5 mm (13.2 x 2.1'); (2) Bottom: 335 x 52.5 mm (13.2 x 2.1')
- Certifications
- Standard: CE; EIA/ECA-310-E; RoHS
- NDAA Compliant: Yes
