PRODUCT SPECIFICATIONS
Ubiquiti UACC-Rack-12U-Wall-600-G 12U Rack Cabinet
The Ubiquiti UACC-Rack-12U-Wall-600-G is a fully assembled 12U wall-mount rack cabinet designed for space-efficient small-scale network deployments. This 600 mm deep enclosed cabinet includes a tempered glass front door, removable lockable side panels, built-in fan module, and a 4-post rack structure for organized equipment access.
The cabinet supports up to 80 kg (176 lb) of equipment and uses square mounting holes with adjustable mounting depth from 448 mm (17.6') to 508 mm (20'). Rear, top, and bottom cable entry openings help support clean cable routing in wall-mounted installations.
Key Features
- Fully assembled 12U wall-mount rack cabinet
- 600 mm deep enclosed 4-post rack design
- Tempered glass front door with reversible left-hand outswing
- Built-in fan module with ≤ 50 dB(A) sound pressure level
- Removable and lockable solid side panels
- Adjustable mounting depth from 448 mm (17.6') to 508 mm (20')
- Rear, top, and bottom cable entry openings
- 80 kg (176 lb) maximum weight capacity
Applications
- Wall-mounted network rack installations where floor space is limited
- Small-scale network equipment deployments requiring an enclosed 12U cabinet
- Installations that need front-door access and removable side panels for equipment service
- Rack setups requiring cable entry through rear, top, or bottom openings
Technical Specifications
- Capacity
- U Height: 12U
- Max. Weight Capacity: 80 kg (176 lb)
- Hardware
- Rack Type: 4 post, enclosed cabinet
- Mounting Hole Type: Square
- Enclosure Material: SPCC steel
- Door/Side Panels: 1.2 mm (0.05')
- Main Body: 1.2 mm (0.05')
- Posts: 2 mm (0.08')
- Color: White
- Treatment: Powder coating
- Front Door: Tempered glass, default left-hand outswing, reversible
- Side Panels: (2) solid, removable and lockable
- Fan Module: Included
- Acoustic Noise: ≤ 50 dB(A) sound pressure level
- Grounding Lugs: Included
- Physical
- Packaging Dimensions: 740 x 730 x 735 mm (29.1 x 28.7 x 28.9')
- Rack Dimensions: 598 x 600 x 639 mm (23.5 x 23.6 x 25.2')
- Packaging Weight: 33.6 kg (74.1 lb)
- Rack Weight: 28.2 kg (62.2 lb)
- Mounting: Wall mount
- Adjustable Mounting Depth: Default 448 mm (17.6'), max. 508 mm (20'), adjustable pitch 20 mm (0.8')
- Cable Entry Opening: (1) rear wall, 350 x 100 mm (13.8 x 3.9')
- Cable Entry Opening: (1) top, 336.5 x 52.5 mm (13.2 x 2.1')
- Cable Entry Opening: (1) bottom, 336.5 x 52.5 mm (13.2 x 2.1')
- Security
- Locks: (1) front door lock, (4) side panel locks, (2) keys
- Certifications
- Standard: CE; EIA/ECA-310-E; RoHS
- NDAA Compliant: Yes
More Information
MFRPartNum:
UACC-Rack-12U-Wall-600-G
