PRODUCT SPECIFICATIONS
USW-PRO-MAX-16 - A 16-port, Layer 3 Etherlighting™ switch 2.5 GbE and versatile mounting options.
A compact, Layer 3, 16-port Etherlighting™ switch featuring versatile mounting options and advanced networking capabilities. Perfect for environments requiring high performance and reliability with intuitive visual feedback.
Features
- Etherlighting™ Ports: Illuminate to indicate port location, speed/link, and native VLAN/network*.
- *Pair with UniFi Etherlighting Patch Cables for optimal brightness.
- Ports:
- (12) GbE RJ45 ports
- (4) 2.5 GbE RJ45 ports
- (2) 10G SFP+ ports
- Mounting Options: Versatile desktop, wall, and rack** mounting.
- **Requires add-on Rack Mount accessory.
- Cooling: Silent, fanless system.
Application
- Data centers
- High-performance networking environments
- Offices and enterprise networks
Dimensions
- 325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7')
Weight
- 1.95 kg (4.3 lb)
Technical Description
- Mechanical
- Enclosure Material: SGCC steel
- Hardware
- Management Interface: Ethernet In-Band
- Networking Interface:
- (12) GbE RJ45 ports
- (4) 1/2.5 GbE RJ45 ports
- (2) 10G SFP+ ports
- Total Non-blocking Throughput: 42 Gbps
- Switching Capacity: 84 Gbps
- Forwarding Rate: 62.496 Mpps
- Power Method: Type-C adapter
- Power Supply: 5V, 25W
- Max Power Consumption: 25W
- LCM Display: (1) 1.3' touchscreen
- Button: Factory reset
- Environmental
- Operating Temperature: -5 to 40°C (23 to 104°F)
- Operating Humidity: 10 to 90% non-condensing
- Certifications: CE, FCC, IC
- Switching Features
- Layer 2 Features:
- IGMP snooping
- STP/RSTP with priorities and port-level disable
- Port isolation
- Storm control
- Voice VLAN
- Port mirroring
- LACP port aggregation
- Multicast/broadcast rate limiting
- MAC address blocking
- Flow control
- 802.1X control
- Jumbo frames
- Proprietary loop protection
- DHCP snooping/guarding
- Egress rate limit
- LLDP-MED
- Port restricted by MAC
- Device isolation with ACLs
- Layer 3 Features:
- DHCP for locally-managed networks
- DHCP relay
- Inter-VLAN routing between networks on the same switch
- Static routing between local networks
- Network isolation with ACLs
- Layer 2 Features:
- Etherlighting™:
- Ethernet: Locating, Speed/link, Native VLAN/network
- SFP+: Locating, Speed/link, Native VLAN/network
- Application Requirements
- UniFi Network: Version 8.1.127 and later
More Information
MFRPartNum:
USW-PRO-MAX-16
