PRODUCT SPECIFICATIONS
Intellinet 560702 8-Port Gigabit Ethernet Desktop Switch
The Intellinet 560702 expands a wired network with eight RJ45 ports supporting 10, 100 and 1000 Mbps connections. Its unmanaged, plug-and-play operation makes it suitable for connecting computers, network printers, NAS devices, gaming consoles, smart TVs and other Ethernet equipment.
Automatic speed detection and Auto-MDI/MDI-X simplify connections to compatible devices, routers and other switches. The compact plastic housing and fanless design suit home offices, small workspaces and entertainment areas where quiet operation matters.
Key Features
- Eight 10/100/1000 Mbps RJ45 Ethernet ports.
- Unmanaged operation with plug-and-play installation.
- 16 Gbps aggregate switching-fabric capacity.
- Auto-MDI/MDI-X on all ports.
- Store-and-forward switching architecture.
- 2,048-entry MAC address table.
- 256 kB buffer memory.
- Support for jumbo frames up to 9 kB.
- IEEE 802.3az Energy Efficient Ethernet.
- Fanless desktop design with plastic housing.
- Included external 5 V DC / 1 A power adapter.
Gigabit Ethernet Performance
Each port negotiates a supported speed with the connected device, allowing 10 Mbps, 100 Mbps and Gigabit equipment to share the same switch. Use suitable Cat5e or Cat6 cabling for Gigabit connections.
The 16 Gbps specification describes aggregate switching-fabric capacity. Each individual port supports a link rate of up to 1 Gbps in each direction at Gigabit full duplex. Actual application throughput depends on connected equipment, cabling and network traffic.
Connectivity and Network Expansion
Any port can connect to a router or another switch. Auto-MDI/MDI-X removes the need to select a dedicated uplink port or crossover cable.
There are eight ports in total. When one port connects to the existing network, seven ports remain available for local devices. A separate router or gateway supplies routing and internet-access functions.
Energy Efficiency and Quiet Operation
Green Ethernet technology reduces unnecessary power use by deactivating unused ports. IEEE 802.3az Energy Efficient Ethernet supports energy-saving operation, while the fanless design avoids cooling-fan noise.
Power and Installation
The switch uses the included external 5 V DC / 1 A power adapter. Its compact enclosure measures 125 mm wide, 65 mm deep and 22 mm high.
This is a non-PoE switch. Its Ethernet ports do not power cameras, access points, IP phones or other connected equipment. Devices requiring PoE need a separately verified compatible injector or another supported power source.
Ideal Applications
- Adding Ethernet connections in a home office.
- Connecting computers, printers and NAS devices.
- Networking smart TVs, media players and gaming consoles.
- Small-office installations requiring simple Gigabit connectivity.
- Quiet desktop network expansion.
Compatible Products
The Intellinet 560702 connects to devices supporting 10BASE-T, 100BASE-TX or 1000BASE-T copper Ethernet through RJ45 ports. Use Cat5e or better cabling for Gigabit operation.
- Intellinet 522533 Gigabit PCI Express Network Card – supports 10/100/1000BASE-T Ethernet and connects to the switch using suitable RJ45 Ethernet cabling. The computer must separately meet the card's installation and driver requirements.
Other suitable equipment includes computers, routers, network printers, NAS devices, smart TVs and gaming consoles with a supported copper Ethernet interface.
Important: This switch does not supply PoE and is not documented as accepting PoE input. Use its included power adapter. Connected PoE-dependent equipment requires a separately verified power source.
Interface limitation: The switch has no SFP or SFP+ slots and does not directly accept optical transceivers. Its ports do not provide 2.5G, 5G or 10G Ethernet link rates.
Technical Specifications
General
- Brand / Manufacturer: Intellinet
- Model / MPN: 560702
- Product Type: Unmanaged desktop Gigabit Ethernet switch
Ethernet Interfaces
- Number of Ports: 8
- Port Type: RJ45 copper Ethernet
- Supported Link Speeds: 10/100/1000 Mbps
- Speed Detection: Automatic
- Auto-MDI/MDI-X: All ports
- Uplink: Any Ethernet port; shares the eight-port total
- Gigabit Cabling: Cat5e or better
- SFP / SFP+ Interfaces: None
- PoE Output: Not supported
Switching
- Switching Fabric: 16 Gbps
- Architecture: Store and forward
- MAC Address Table: 2,048 entries
- Buffer Memory: 256 kB
- Jumbo Frames: Up to 9 kB
- Flow Control: IEEE 802.3x and backpressure
Supported Standards
- IEEE 802.3 — 10BASE-T Ethernet
- IEEE 802.3u — 100BASE-TX Fast Ethernet
- IEEE 802.3ab — 1000BASE-T Gigabit Ethernet
- IEEE 802.3x — Flow control
- IEEE 802.3az — Energy Efficient Ethernet
Power
- Power Source: Included external AC-to-DC adapter
- Specified Adapter DC Output: 5 V / 1 A
- Switch Power Connection: DC input jack
Physical Specifications
- Housing: Plastic
- Cooling: Fanless
- Installation: Desktop
- Dimensions, W × D × H: 125 × 65 × 22 mm (4.92 × 2.56 × 0.87 inches)
- Weight: Requires confirmation due to conflicting published values
- Indicators: Power and Link/Activity LEDs
Environmental
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Humidity: 10–90%, non-condensing
Documented Compliance
- FCC Class B
- CE
- RoHS
Included Parts
- 560702 8-Port Gigabit Ethernet Switch.
- Power adapter.
- User manual.
