Ubiquiti UACC-ENVR-Bezel 4.7" Touchscreen Faceplate for ENVR LED Disk Security

Ubiquiti UACC-ENVR-Bezel Enterprise NVR Bezel

Faceplate that integrates with Enterprise Network Video Recorder to provide a 4.7' touch display and LED illumination.

Key Features

• Disc overview and management
• View livestreams directly from the rack
• Physically secure discs with a door latch
• 4.7' touchscreen
• Compatibility: ENVR

Note: Support ENVR firmware version 4.1.10 and later.

Technical Specification

• Mechanical:
  • Dimensions: 441.7 x 132 x 51.9 mm (17.4 x 5.2 x 2')
  • Weight: 1.1 kg (2.3 lb)
  • Enclosure Material: Polycarbonate
• Hardware:
  • Power Method: Magnetic Type-C
  • Supported Voltage Range: 5V
  • Max. Power Consumption: 3.78W
  • ESD/EMP Protection: Air: ± 12kV, contact: ± 8kV
  • LCM Display: (1) 4.7' touchscreen
  • LEDs:
    • Boot sequence wave pattern
    • User configurable status
    • Locate function
  • Ambient Operating Temperature: -5 to 40° C (23 to 104° F)
  • Ambient Operating Humidity: 5 to 95% noncondensing
  • Certifications: CE, IC, FCC
