PRODUCT SPECIFICATIONS
Ubiquiti UA-Hub-Gate Gate Access Control Hub
The Ubiquiti UA-Hub-Gate is an access control hub for one gate and one side door. It enables gate access control through connected Access readers or an Intercom and provides PoE outputs for readers and a camera.
Compatibility
- UVC-AI-MS-4-W
- UVC-AI-PTZ-Precision-B
- UVC-AI-PTZ-Precision-W
- UVC-AI-Dome-B
- UVC-AI-Dome-W
- UVC-AI-DSLR
- UVC-AI-DSLR-LD
- UVC-AI-Pro
- UVC-AI-Pro-White
- UVC-G6-Bullet-B
- UVC-G6-Bullet-W
- UVC-AI-Theta
- UVC-G6-PTZ-B
- UVC-G6-PTZ-W
- UVC-AI-Turret-B
- UVC-AI-Turret-W
- UVC-AI-PTZ-B
- UVC-AI-PTZ-W
- UVC-AI-Bullet
- UVC-G6-Turret-B
- UVC-G6-Turret-W
Key Features
- (4) PoE outputs for readers and camera
- (2) inputs for gate exit request and side door position
- (1) emergency input
- (2) dry gate operator output relays
- (1) side door lock output relay
- (1) factory-reset button
- Supports one gate and one side door
- DIN-rail mount included
Technical Specifications
- Ports / Interfaces
- Networking interface: (5) 10/100/1000 Base-T
- Digital input: Gate exit request, gate position, side door exit request, side door position, emergency
- Dry output relay: (2) operator, rated 30V DC, up to 1A; (1) aux, rated 30V DC, up to 1A
- Powered output relay: Side door lock, 12V DC, up to 1A
- Hardware
- Supported doors: 1 gate, 1 side door
- LEDs: W/B
- Buttons: (1) factory-reset
- Power
- Power method: PoE++; UL 294 Power-limited Class 2 PSU; UL 60950-1/62368-1 LPS/PS2 PSU
- PoE interface: (1) PoE++ input, 50V DC, 1A; (4) PoE outputs, 50V DC, max. 28W
- Max. power consumption: 22W without PoE output; 50W with PoE output
- Physical
- Dimensions: 175 x 126 x 26 mm (6.9 x 5 x 1')
- Weight: 460 g (1 lb)
- Enclosure material: Polycarbonate
- Mounting: DIN-rail mount included
- Indoor and outdoor use: Device itself is indoor only; outdoor use requires a waterproof junction box
- Environmental
- Ambient operating temperature: -30 to 60° C (-22 to 104° F)
- Ambient operating humidity: 5 to 90% noncondensing
- Certifications
- CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
